在開發Windows桌面應用程序時，我們經常需要在自己的應用程序中嵌入并控制其他可執行程序。本文將詳細介紹如何在C# WinForms應用程序中實現這一功能，并提供多個實用示例。
基本概念 嵌入外部程序意味著將其他Windows應用程序的窗口作為子窗口嵌入到我們的WinForms應用程序中。這種技術通常用于：
集成第三方工具 創建復合應用程序 提供統一的用戶界面 控制和管理多個應用程序 技術實現 基本實現類 創建一個專門用于管理嵌入程序的類：
using System; using System.Collections.Generic; using System.Diagnostics; using System.Linq; using System.Runtime.InteropServices; using System.Text; using System.Threading.Tasks; namespace AppEmbedding { public class ExternalProcessManager { // Windows API 常量 private const int GWL_STYLE = -16 ; private const int WS_CHILD = 0x40000000 ; private const int WS_VISIBLE = 0x10000000 ; // Windows API 聲明 private static class WindowsAPI { [DllImport( "user32.dll" )] public static extern IntPtr SetParent (IntPtr hWndChild, IntPtr hWndNewParent) ; [DllImport( "user32.dll" )] public static extern int GetWindowLong (IntPtr hWnd, int nIndex) ; [DllImport( "user32.dll" )] public static extern int SetWindowLong (IntPtr hWnd, int nIndex, int dwNewLong) ; [DllImport( "user32.dll" )] public static extern bool ShowWindow (IntPtr hWnd, int nCmdShow) ; [DllImport( "user32.dll" )] public static extern bool MoveWindow (IntPtr hWnd, int X, int Y, int nWidth, int nHeight, bool bRepaint) ; } private Process _embeddedProcess; private Control _parentControl; public ExternalProcessManager (Control parentControl) { _parentControl = parentControl; } public void EmbedProcess ( string processPath) { try { // 啟動進程 - 使用 UseShellExecute = false 可能對某些應用程序更有效 ProcessStartInfo startInfo = new ProcessStartInfo(processPath) { UseShellExecute = false , CreateNoWindow = false }; _embeddedProcess = Process.Start(startInfo); // 使用超時機制等待窗口句柄創建，避免無限等待 _embeddedProcess.WaitForInputIdle( 3000 ); // 設置等待主窗口句柄的超時時間 DateTime timeout = DateTime.Now.AddSeconds( 5 ); while (_embeddedProcess.MainWindowHandle == IntPtr.Zero) { if (DateTime.Now > timeout) { throw new TimeoutException( "無法獲取進程主窗口句柄" ); } Application.DoEvents(); // 保持UI響應 System.Threading.Thread.Sleep( 100 ); } // 設置父窗口 WindowsAPI.SetParent(_embeddedProcess.MainWindowHandle, _parentControl.Handle); // 設置窗口樣式 int style = WindowsAPI.GetWindowLong(_embeddedProcess.MainWindowHandle, GWL_STYLE); style |= WS_CHILD | WS_VISIBLE; // 添加WS_VISIBLE確保窗口可見 WindowsAPI.SetWindowLong(_embeddedProcess.MainWindowHandle, GWL_STYLE, style); // 調整窗口位置和大小 WindowsAPI.MoveWindow( _embeddedProcess.MainWindowHandle, 0 , 0 , _parentControl.ClientSize.Width, _parentControl.ClientSize.Height, true ); // 確保父控件在尺寸變化時調整嵌入程序的大小 _parentControl.SizeChanged += (sender, e) => { if (_embeddedProcess != null && !_embeddedProcess.HasExited) { WindowsAPI.MoveWindow( _embeddedProcess.MainWindowHandle, 0 , 0 , _parentControl.ClientSize.Width, _parentControl.ClientSize.Height, true ); } }; } catch (Exception ex) { MessageBox.Show($ "嵌入進程時出錯: {ex.Message}" , "錯誤" , MessageBoxButtons.OK, MessageBoxIcon.Error); } } public void CloseEmbeddedProcess () { if (_embeddedProcess != null && !_embeddedProcess.HasExited) { try { _embeddedProcess.CloseMainWindow(); if (!_embeddedProcess.WaitForExit( 3000 )) { _embeddedProcess.Kill(); } } catch (Exception ex) { MessageBox.Show($ "關閉進程時出錯: {ex.Message}" , "錯誤" , MessageBoxButtons.OK, MessageBoxIcon.Error); } finally { _embeddedProcess.Dispose(); _embeddedProcess = null; } } } } } 實際應用示例 嵌入記事本示例 public partial class NotePadForm : Form { private ExternalProcessManager _processManager; public NotePadForm () { InitializeComponent(); // 創建一個Panel用于容納記事本 Panel notepadPanel = new Panel { Dock = DockStyle.Fill }; this .Controls.Add(notepadPanel); _processManager = new ExternalProcessManager(notepadPanel); } private void btnEmbedNotepad_Click (object sender, EventArgs e) { _processManager.EmbedProcess( "notepad.exe" ); } protected override void OnFormClosing (FormClosingEventArgs e) { _processManager.CloseEmbeddedProcess(); base.OnFormClosing(e); } }
嵌入計算器示例 public partial class CalculatorForm : Form { private ExternalProcessManager _processManager; private Panel _calcPanel; public CalculatorForm () { InitializeComponent(); // 創建計算器面板 _calcPanel = new Panel { Size = new Size( 300 , 400 ), Location = new Point( 10 , 10 ) }; this .Controls.Add(_calcPanel); _processManager = new ExternalProcessManager(_calcPanel); Button embedButton = new Button { Text = "嵌入計算器" , Location = new Point( 320 , 10 ) }; embedButton.Click += EmbedCalculator_Click; this .Controls.Add(embedButton); } private void EmbedCalculator_Click (object sender, EventArgs e) { _processManager.EmbedProcess( "calc.exe" ); } protected override void OnFormClosing (FormClosingEventArgs e) { _processManager.CloseEmbeddedProcess(); base.OnFormClosing(e); } } 常見問題解決 窗口無法正確嵌入
// 確保等待窗口句柄創建 while (process.MainWindowHandle == IntPtr.Zero) { System.Threading.Thread.Sleep( 100 ); process.Refresh(); } DPI縮放問題
protected override void OnLoad (EventArgs e) { base.OnLoad(e); if (Environment.OSVersion.Version.Major >= 6 ) { SetProcessDPIAware(); } } [DllImport( "user32.dll" )] private static extern bool SetProcessDPIAware () ; 窗口大小調整
protected override void OnResize (EventArgs e) { base.OnResize(e); if (_embeddedProcess != null && !_embeddedProcess.HasExited) { WindowsAPI.MoveWindow(_embeddedProcess.MainWindowHandle, 0 , 0 , _parentControl.Width, _parentControl.Height, true ); } } 總結 通過本文的詳細介紹和示例，你應該能夠在C# WinForms應用程序中成功實現外部程序的嵌入和控制。記住要注意進程管理、窗口處理、性能優化和安全性等關鍵方面。合理使用這些技術可以幫助你創建更強大和靈活的應用程序。
?
